This technical article provides a standardized interpretation of high-precision plastic film flexographic printing presses developed by Zhejiang Trust Machinery Co., Ltd. As a global supplier with 15 years of R&D and industrial experience in flexo printing, blown film and bag making machinery, we drive industry technological advancement. Our presses are tailored for medium-to-large flexible packaging enterprises and high-precision sectors, solving core pain points like registration drift, ink offset, and lengthy changeovers. Adhering strictly to ISO 9001 and CE standards, we achieve breakthroughs in ±0.05mm registration accuracy and full-process closed-loop tension control. Our products are exported to dozens of countries, serving clients in food packaging, personal care, and pharmaceutical sectors, and are recognized as reliable solutions with ISO and CE certifications.
Plastic film flexographic printing presses are roll-to-roll systems using flexible relief plates, optimized for high-speed, high-precision printing on plastic substrates. Based on servo-driven closed-loop control technology, these machines ensure stable, consistent printing across diverse production scenarios. As a core solution in the flexible packaging machinery sector, they are indispensable for efficient, high-quality packaging production.
Main Categories
1. High-Speed Series: Designed for large-batch production, with a design speed of 220 m/min, ideal for food and personal care packaging, featuring dual-stage electric drying and anti-clogging anilox rollers.
2. Standard Precision Series: Balances speed and flexibility, with a design speed of 150 m/min, suitable for multi-variety small-batch production, equipped with intelligent centralized control and quick-change sleeve structure.
3. Custom Wide-Format Series: Supports web widths up to 1600mm, tailored for industrial packaging, offering fully customizable color units and configurations.
Design Philosophy: Our products prioritize precision, reliability, and deep customization, following full-life-cycle reliability standards to deliver stable, cost-effective solutions for harsh industrial scenarios.
The core working principle of our presses is based on Siemens PLC-controlled servo-driven closed-loop systems. The operational link includes:
1. Unwind Stage: Tension sensors detect material slack or stretch, sending real-time data to the PLC for automatic compensation to prevent registration drift.
2. Printing Stage: Independent servo motors and precision ball screws drive horizontal and vertical registration, with photoelectric encoders providing real-time feedback to maintain ±0.05mm accuracy.
3. Drying Stage: A dual-stage electric drying system uses high-temperature airflow to ensure thorough ink curing before the next color station, eliminating ink offset.
Core Architecture & Innovative Design
- Siemens PLC Control Module: Centralizes parameter management, stores job recipes, and tracks historical data to simplify changeovers.
- Closed-Loop Tension Control Module: Provides automatic detection and compensation from unwind to rewind, ensuring stability across diverse substrates.
Compared to traditional mechanical-shaft presses, our servo-driven system reduces registration deviation by 90% and cuts changeover time by 60%, addressing long-standing industry pain points.
All parameters are tested strictly per ISO standards, with clear test conditions and tolerance controls. We provide full parameter test reports for each batch, supporting third-party inspection.
Core Performance Parameters
- Registration Accuracy: ±0.05mm, tested at 150 m/min with PE film, critical for pharmaceutical and food packaging.
- Design Speed: 120–220 m/min, actual production speed 30–170 m/min depending on substrate complexity, suitable for different production scales.
- Web Width: Standard 1000–1200mm, customizable to 800mm or 1400–1600mm, ideal for various packaging sizes.
- Anilox Roller Resolution: 100–1200 lines per inch, micron-level precision, supporting diverse ink transfer requirements.
1. Industry-Leading Registration Accuracy
Technical Support: Independent servo motors, precision ball screws, real-time photoelectric encoder feedback; 60 independent patents and national high-tech enterprise certification.
Quantifiable Data: ±0.05mm registration accuracy, meeting strict requirements of food and pharmaceutical packaging.
Customer Value: Reduces product scrap rate by 30%, ensuring consistent print quality across high-speed production.
2. Full-Process Closed-Loop Tension & Drying System
Technical Support: Automatic tension detection from unwind to rewind; dual-stage electric drying with main oven and inter-color drying.
Quantifiable Data: Reduces material stretch-related registration drift by 90%, eliminates ink offset at high speeds.
Customer Value: Improves production efficiency by 20%, minimizes waste and rework costs.
Our presses follow strict global standards throughout R&D, production and testing, meeting diverse regional and industry requirements.
Core International Standards: ISO 9001 Quality Management System, CE Safety Standards for Machinery, UL Electrical Component Standards.
Authoritative Certifications: ISO 9001 certification, CE product certification, with independent import and export rights for global trade.
Documentation Support: We provide SGS/TÜV third-party test reports, factory inspection reports, and compliance declarations upon request.
Q: What plastic materials can your flexo printing machines handle?
A: Our machines support PE, HDPE, LDPE, LLDPE, OPP, BOPP, PET films, and we can recommend customized configurations based on specific material specifications.
Q: How does your machine maintain registration accuracy at high speeds?
A: We use independent servo motors, precision ball screws, and real-time photoelectric encoder feedback to achieve ±0.05mm registration accuracy, eliminating drift caused by material stretching.
Q: Can you customize machines for special requirements?
A: Yes, we offer deep customization including web widths up to 1600mm, extra color units, and special configurations for industrial packaging or premium applications.
